Good quality spindle tape not only can increase the competitiveness of spinning machine manufacturer, but also can ensure the spinning mil get better yarn. GC has never stop their step to provide high performance spindle tapes to both these two kinds of clients.
GC offers a very broad range of polyamide spindle tape and polyester spindle tapes, which are ideal for cotton, woollen, worsted & synthetic fibber spinning. With thickness from 0.55 mm to 0.9mm, spindle tapes from GC are suitable for four-spindle, eight-spindle and multiple-spindle drive occasions, such as spinning frame, twisting machine. In the mean time, they can meet the different requirements of spindle speed and have following features
Dimensional stability
Excellent tape flexibility
Easy and quick splicing
Saving energy consumption
Without fiber and fluff accumulation
Constant spindle speed and yarn quality
High abrasion resistance and long usage life
Product
Type | Product
Code | Thickness | Tensile Strength | Min Pulley | Temperature Resistance |
mm | N/mm | mm | ℃ | ||
Spindle Tape | GC-DPAD08 | 0.8 | 60.0 | 20 | -20～100 |
GC-DPAD07 | 0.7 | 50.0 | 15 | -20～100 | |
GC-DPAD55 | 0.55 | 60.0 | 12 | -20～100 | |
GC-DPAH07 | 0.7 | 90.0 | 15 | -20～100 | |
GC-DPAH09 | 0.9 | 109.0 | 15 | -20～100 | |
GC-DPEH09 | 0.9 | 40.0 | 15 | -20～60 | |
GC-DPAT06 | 0.6 | N/A | 15 | -20～100 | |
GC-DPET09 | 0.9 | N/A | 20 | -20～100 |
Currently, GC mainly provide three types of spindle belts in terms of thickness. The first one is conventional type with a thickness exceeding 0.7mm, the second one is ultra-thin type with a thickness between 0.55mm and 0.65mm, and the third one is finger jointing type with a thickness of 0.7mm. Generally speaking, the first one is more price competitive due to its’ maturer processing technology, while the latter two types have better operation performance. You can choose the right one according to your specific usage requirements, feel free to contact GC sales team for more details about our spindle tapes.
